Makita 9566PC 6″ SJS™ High-Power Paddle Switch Cut-Off/Angle Grinder

Brand: Makita

Color: Factory

Features:

n
• SJS technology is a mechanical clutch system that helps prevent motor and gear damage by allowing the drive shaft to slip if the wheel is forced to stop

n

• Constant speed control automatically applies additional power to the motor to maintain speed under load

n

• Soft start suppresses start-up reaction for smooth start-ups and longer gear life

n

• Soft start suppresses start-up reaction for smooth start-ups and longer gear life

n

• Makita 9566PC 6″ SJS High-Power Paddle Switch Cut-Off/Angle Grinder

n

Binding: Tools & Home Improvement

model number: 9566PC

Part Number: 9566PC

Details: Amazon.com
n
nMakita’s 6-Inch SJS Cut-Off/Angle Grinder combines 13 AMP power with comfort and motor-protection features for longer-lasting industrial performance. The 9566PC is engineered with Makita’s innovative Super Joint System (SJS) to protect the gears for longer tool life.
n.c26-caption {font-family: Verdana, Helvetica neue, Arial, serif;font-size: 10px;font-weight: bold;font-style: italic;}.c26-matrix1a {font-family: Verdana, Helvetica neue, Arial, serif;font-size: 10px;background-color: #bcbec0;}.c26-matrix1b {font-family: Verdana, Helvetica neue, Arial, serif;font-size: 10px;background-color: #a7a9ac;}.c26-matrix1h {font-family: Verdana, Helvetica neue, Arial, serif;font-size: 11px;font-weight: bold;color: #ffffff;background-color: #008b97;text-align: center;}img.c26-border {border:1px black solid;}a.nodecoration {text-decoration: none}
n
nView larger9566PC FeaturesPOWER – 13 AMP motor delivers 10,000 RPMPERFORMANCE – Super Joint System (SJS) helps prevent gear damageDURABILITY – Labyrinth construction, zig-zag varnish and thicker coil wires for longer tool lifeCOMFORT – Large paddle switch for easy operation; only 4.2 lbs.INCLUDES – Cut-off wheel, wheel guard, side handle, inner flange, lock-nut and wrench
nTool SpecificationsGrinding wheel6″Cut-off wheel6″Wire cup brush3-1/2″Sanding disc6″No load speed10,000 RPMSpindle thread5/8″-11 UNCAMPS13.0Overall length12-1/8″Net weight4.2 lbs.13 AMP Power with SJS to Protect Gears
nThe 9566PC is powered by a 13 AMP motor that delivers 11,500 RPM, with soft start for smooth start-ups. Labyrinth construction protects the motor with a complex set of channels, prohibiting dust and contamination. In addition, the protective zig-zag varnish seals the motor and bearings from dust and debris by creating a barrier under rotation. The 9566PC is engineered with SJS, an innovation from Makita that protects the gears by automatically disengaging the motor should the grinding wheel accidentally catch or bind.
nComfort and Ergonomics
nThe 9566PC weighs just 4.2 pounds and is built with comfort and ergonomic features for extended use. The paddle switch provides easy operation, and the gear housing can be positioned every 90° for operator convenience. In addition, the side handle can be easily installed on either side of the tool as well as the top, and the “tool-less” wheel guard adjustment provides easy clamping.
nVersatile Design for a Range of Applications
nThe 9566PC is a versatile and powerful grinder engineered for demanding applications including cutting, ferrous metal, paint and rust removal, shipyard maintenance, heavy machinery, metal polishing, general steel grinding, auto repair work, cutting brick and masonry, and restoration work. The grinder is built for welders, fabricators, plumbers, masons, electricians, automotive technicians, stone and tile workers, HVAC, and general contractors seeking a best-in-class industrial quality cut-off/angle grinder. The 9566PC is just another example of Makita’s commitment to innovative technology and best-in-class engineering.
nAbout Makita’s Super Joint System (SJS)
nSuper Joint System (SJS) is an innovation from Makita engineering where the motor armature and spiral bevel gear are linked by a coil spring. If the grinding wheel catches or binds, the coil spring relaxes and disengages the gears from the motor. As the grinding wheel stops, the gears and motor are protected. Makita’s growing line of SJS-equipped grinders includes models ranging from a 1/4″ die grinder to a 7-inch angle grinder.
nAbout Makita
nMakita is a worldwide manufacturer of industrial quality power tools and offers a wide range of industrial accessories. Makita applies leading-edge innovation to engineer power tools that are more compact and energy efficient, yet deliver industrial strength power and results. Makita U.S.A., Inc. is located in La Mirada, California, and operates an extensive distribution network located throughout the U.S. For more information, please call 800/4-MAKITA (800/462-5482) or visit makitatools.com. Makita is Best in Class Engineering.
nWarranty
nEvery Makita tool is thoroughly inspected and tested before leaving the factory. If you are not satisfied with any Makita tool within 30 days of purchase, return it and Makita will provide a replacement or refund. Each Makita tool is warranted to be free of defects from workmanship and materials for the period of ONE YEAR from the date of original purchase. Should any trouble develop during this one-year period, return the COMPLETE tool, freight prepaid, to one of Makita’s Factory or Authorized Service Centers. Please see makitatools.com for complete details.
nWhat’s in the Box
nMakita 9566PC 6-Inch 13 AMP SJS Cut-Off/Angle Grinder with Paddle Switch, 6-inch cut-off wheel, side handle, cut-off wheel guard, inner flange, lock nut and lock nut wrench.
n
n
n
n
n
nProduct Description
n
nRight Angle Grinder, SJS Paddle Switch Type, Free Speed (RPM) 10000, Wheel Dia. (In.) 6 In., Spindle Size (In.) 5/8 In., Length (I

EAN: 0088381085182

Package Dimensions: 15.2 x 5.8 x 5.7 inches
