Fasco A212 Centrifugal Blower with Sleeve Bearing, 2,500 rpm, 115V, 60Hz, 1.25 amps

Brand: Fasco

Features:

n
• 212 CFM free air output-rated centrifugal blower for use in heating and ventilation appliances

n

• Sleeve bearing for blower motor shaft support

n

• 115V, 60Hz, 1.25 amps power input for multiple uses

n

• 190 CFM air flow rate at 0.1″ SP

n

• UL recognized and CSA certified for quality assurance

n

Release Date: 12-03-2017

model number: A212

Part Number: A212

Details: This Fasco A212 centrifugal blower accepts 115V, 60 Hz, 1.25 amps power input and has a sleeve bearing for blower motor shaft support. The single-speed, dual inlet blower has a free air output rating of 212 cubic feet per minute (CFM) at 2,500 revolutions per minute (RPM). The blower produces 190 CFM of air flow at 0.1″ (inches water gauge) static pressure (SP), 173 CFM at 0.2″, 142 CFM at 0.3″, 110 CFM at 0.4″, 70 CFM at 0.5″, and 22 CFM at 0.6″. The motor is thermally protected to guard against overheating. This centrifugal blower is Underwriters Laboratories (UL) recognized and Canadian Standards Association (CSA) certified for quality assurance and is suitable for use in heating and ventilation applications such as exhaust vent fans for furnaces. SpecificationsMotor1-speed, 115V, 60 Hz, 1.25 amp, sleeve bearing, thermally protectedBlower typeCentrifugal, dual inletFree air output212 CFM at 2,500 RPMCFM at static pressure (SP)190 CFM of air flow at 0.1″ SP, 173 CFM at 0.2″, 142 CFM at 0.3″, 110 CFM at 0.4″, 70 CFM at 0.5″, and 22 CFM at 0.6″Specifications metUL recognized, CSA certified
n
nFasco manufactures blowers and motors for heating, ventilation, and cooling systems. The company, founded in 1911, is headquartered in Springfield, MO.

EAN: 0663001021735

Package Dimensions: 16.2 x 5.6 x 5.3 inches
